A visual brush is used to fill a region with a vector drawing. More...

#include <idombrush.h>

Inheritance diagram for IDOMVisualBrush:

[legend]

Classes
class	Data
	Initialization data. More...

Public Member Functions
virtual eTilingMode	getTileMode () const =0
	Retrieves the tiling mode value of the visual brush. More...

virtual void	setTileMode (eTilingMode tm)=0
	Sets tiling mode value of the visual brush. More...

virtual eViewUnits	getViewBoxUnits () const =0
	Retrieves the viewbox units used by the image brush. Currently, only absolute units are supported. More...

virtual void	setViewBoxUnits (eViewUnits vu)=0
	Sets the viewbox units value of the image brush. Currently, only absolute units are supported. More...

virtual eViewUnits	getViewPortUnits () const =0
	Retrieves the viewport units value of the image brush. Currently, only absolute units are supported. More...

virtual void	setViewPortUnits (eViewUnits vu)=0
	Sets the viewport units used for the image brush. Currently, only absolute units are supported. More...

virtual const FRect &	getViewBox () const =0
	Retrieves the viewbox rectangle. More...

virtual void	setViewBox (const FRect &vb)=0
	Sets viewbox rectangle. More...

virtual const FRect &	getViewPort () const =0
	Retrieves the viewport rectangle. More...

virtual void	setViewPort (const FRect &vp)=0
	Sets the viewport rectangle. More...

virtual IDOMNodePtr	getVisual () const =0
	Retrieves smart pointer to the visual node (path, glyphs, group or canvas node) used to specify the source for the visual brush. More...

virtual void	setVisual (const IDOMNodePtr &ptrVisual)=0
	Sets the visual node (path, glyphs or canvas node) used to specify the source for the visual brush. More...

virtual IDOMTilingPatternBrushPtr	getEquivalentTilingBrush (IEDLClassFactory *pFactory)=0
	Gets an equivalent IDOMTilingPattern brush. If the receiver has a tile mode of eNoTile, this call will fail. More...

virtual IDOMVisualBrushPtr	getEquivalentSimpleVisualBrush (IEDLClassFactory *pFactory)=0
	Gets an equivalent visual brush where any flip tile mode is simplified to simple tiling. Useful for situations where flipping cannot be handled, but simple visual brushes can. More...

Public Member Functions inherited from IDOMTransformableBrush
virtual const FMatrix &	getRenderTransform () const =0
	Retrieves the render transform matrix. More...

virtual void	setRenderTransform (const FMatrix &matrix)=0
	Sets the render transform matrix. More...

Public Member Functions inherited from IDOMBrush
virtual eBrushType	getBrushType () const =0
	Retrieves the type of the brush. More...

virtual float	getOpacity () const =0
	Retrieves the opacity value of the brush element. More...

virtual void	setOpacity (float opc)=0
	Sets the opacity value of a brush element. More...

virtual IDOMBrushPtr	getAdjustedForUseInTransformedNode (IEDLClassFactory *pFactory, const FMatrix &nodeTransform)
	Get a version of this brush adjusted for use inside a node with the given transform. More...

Public Member Functions inherited from IEDLObject
virtual const CClassID &	getClassID () const =0
	Returns class ID of IEDLObject. More...

virtual bool	init (CClassParams *pData)
	The init() method is called to perform any post-construction initialization of an IEDLObject that has been created by the EDL class factory, before it is actually returned by the factory. More...

virtual bool	clone (IEDLObjectPtr &ptrObject, IEDLClassFactory *pFactory)
	Create a copy of EDLObject. More...

Public Member Functions inherited from IRCObject
virtual void	addRef () const =0
	Increases the reference count of the actual object pointed to. This would take place during an assignment or copying.

virtual bool	decRef () const =0
	Decreases the reference count of the actual object pointed to. When the reference count falls to Zero, it deletes the actual object pointed to. More...

virtual int32	getRefCount () const =0
	Retrieve the current reference count of the actual object pointed to. More...

Static Public Member Functions
static EDL_API IDOMVisualBrushPtr	create (IEDLClassFactory *pFactory, const IDOMNodePtr &visual, const FRect &viewBox, const FRect &viewPort, const FMatrix &renderTransform=FMatrix(), float opacity=1.0f, eTilingMode tileMode=eNoTile)
	Simplified creator for a visual brush. Throws an IEDLError on failure. More...

static const CClassID &	classID ()
	Retrieves the class id of IDOMVisualBrush. More...

Additional Inherited Members
Public Types inherited from IDOMBrush
enum	eBrushType { eSolidColor , eLinearGradient , eRadialGradient , eImage , eMasked , eVisual , eSoftMask , eTilingPattern , eType1ShadingPattern , eType2ShadingPattern , eType3ShadingPattern , eType4567ShadingPattern , eNull }
	Brush type enumeration. More...

Protected Member Functions inherited from IRCObject
virtual	~IRCObject ()
	Virtual destructor.

Detailed Description

A visual brush is used to fill a region with a vector drawing.

The drawing may be specified as either a visual brush property or as a resource reference. The drawing content may include exactly one Canvas, Path, or Glyphs node and that node's child and descendant nodes.

Visual brushes share a number of tile-related properties with image brushes.

See also: IDOMImageBrush

Member Function Documentation

◆ classID()

static const CClassID& IDOMVisualBrush::classID ( )

inlinestatic

Retrieves the class id of IDOMVisualBrush.

Returns: CClassID The class id of IDOMVisualBrush.

◆ create()

static EDL_API IDOMVisualBrushPtr IDOMVisualBrush::create	(	IEDLClassFactory *	pFactory,
		const IDOMNodePtr &	visual,
		const FRect &	viewBox,
		const FRect &	viewPort,
		const FMatrix &	renderTransform = `FMatrix()`,
		float	opacity = `1.0f`,
		eTilingMode	tileMode = `eNoTile`
	)

static

Simplified creator for a visual brush. Throws an IEDLError on failure.

Parameters

pFactory	The factory to use.
visual	The node to use as the visual.
viewBox	The desired view box.
viewPort	The desired view port.
renderTransform	The desired render transform.
opacity	The desired brush opacity.
tileMode	The desired tile mode.

Returns: IDOMVisualBrushPtr The new visual brush.

◆ getEquivalentSimpleVisualBrush()

virtual IDOMVisualBrushPtr IDOMVisualBrush::getEquivalentSimpleVisualBrush ( IEDLClassFactory * pFactory )

pure virtual

Gets an equivalent visual brush where any flip tile mode is simplified to simple tiling. Useful for situations where flipping cannot be handled, but simple visual brushes can.

Parameters

pFactory A pointer to an EDL class factory.

Returns: IDOMVisualBrushPtr The equivalent visual brush, or this brush if no changes are required. This brush will be cached, so do not edit; make a clone if the returned brush needs to be changed.

◆ getEquivalentTilingBrush()

virtual IDOMTilingPatternBrushPtr IDOMVisualBrush::getEquivalentTilingBrush ( IEDLClassFactory * pFactory )

pure virtual

Gets an equivalent IDOMTilingPattern brush. If the receiver has a tile mode of eNoTile, this call will fail.

Parameters

pFactory A pointer to an EDL class factory

Returns: IDOMTilingPatternBrushPtr The equivalent tiling brush, or NULL if a tiling brush cannot be created for this brush. This brush will be cached, so do not edit; make a clone if the returned brush needs to be changed.

◆ getTileMode()

virtual eTilingMode IDOMVisualBrush::getTileMode ( ) const

pure virtual

Retrieves the tiling mode value of the visual brush.

Returns: eTilingMode The tiling mode

See also: eTilingMode

◆ getViewBox()

virtual const FRect& IDOMVisualBrush::getViewBox ( ) const

pure virtual

Retrieves the viewbox rectangle.

The viewbox specifies the portion of a source image or visual to be rendered to the page as a tile, whose size and location are determined by the image brush's viewport. The tile is then used to fill the geometry specified by the parent element according to the image brush's tile mode. The ViewBox can specify a region larger than the image itself, including negative values. The view box specifies the position and dimension of the brush's source content. It is specified by four comma-separated real numbers (x, y, width, height) where width and height are non-negative.

Returns: FRect The viewbox

◆ getViewBoxUnits()

virtual eViewUnits IDOMVisualBrush::getViewBoxUnits ( ) const

pure virtual

Retrieves the viewbox units used by the image brush. Currently, only absolute units are supported.

See also: getViewBox(); setViewBox()

Returns: eViewUnits The viewbox units.

◆ getViewPort()

virtual const FRect& IDOMVisualBrush::getViewPort ( ) const

pure virtual

Retrieves the viewport rectangle.

The viewport specifies the dimensions and location of the initial tile that will be filled with the specified image or visual fragment. It is defined in the current effective coordinate space. It is specified by four comma separated real numbers (x, y, width, height) where width and height are non-negative.

Returns: FRect The viewport rectangle

◆ getViewPortUnits()

virtual eViewUnits IDOMVisualBrush::getViewPortUnits ( ) const

pure virtual

Retrieves the viewport units value of the image brush. Currently, only absolute units are supported.

See also: getViewPort(); setViewPort()

Returns: eViewUnits The viewport units.

◆ getVisual()

virtual IDOMNodePtr IDOMVisualBrush::getVisual ( ) const

pure virtual

Retrieves smart pointer to the visual node (path, glyphs, group or canvas node) used to specify the source for the visual brush.

Returns: IDOMNodePtr The visual

◆ setTileMode()

virtual void IDOMVisualBrush::setTileMode ( eTilingMode tm )

pure virtual

Sets tiling mode value of the visual brush.

Parameters

tm	The tiling mode value

See also: eTilingMode

◆ setViewBox()

virtual void IDOMVisualBrush::setViewBox ( const FRect & vb )

pure virtual

Sets viewbox rectangle.

The viewbox specifies the portion of a source image or visual to be rendered to the page as a tile. The tile is then used to fill the geometry specified by the parent element according to the TileMode() function. The viewbox can specify a region larger than the image itself, including negative values. The viewbox specifies the position and dimension of the brush's source content. It is specified by four comma-separated real numbers (x, y, width, height) where width and height are non-negative.

Parameters

vb	The viewbox rectangle

◆ setViewBoxUnits()

virtual void IDOMVisualBrush::setViewBoxUnits ( eViewUnits vu )

pure virtual

Sets the viewbox units value of the image brush. Currently, only absolute units are supported.

See also: getViewBox(); setViewBox()

Parameters

vu	The viewbox units value

◆ setViewPort()

virtual void IDOMVisualBrush::setViewPort ( const FRect & vp )

pure virtual

Sets the viewport rectangle.

The viewport specifies the dimensions and location of the initial tile that will be filled with the specified image or visual fragment. It is defined in the current effective coordinate space. It is specified by four comma separated real numbers (x, y, width, height) where width and height are non-negative.

Parameters

vp	The viewport rectangle

◆ setViewPortUnits()

virtual void IDOMVisualBrush::setViewPortUnits ( eViewUnits vu )

pure virtual

Sets the viewport units used for the image brush. Currently, only absolute units are supported.

See also: getViewPort(); setViewPort()

Parameters

vu	The new viewport units value

◆ setVisual()

virtual void IDOMVisualBrush::setVisual ( const IDOMNodePtr & ptrVisual )

pure virtual

Sets the visual node (path, glyphs or canvas node) used to specify the source for the visual brush.

Parameters

ptrVisual Pointer to the visual node (path, glyphs or canvas node) used to specify the source for the visual brush.

The documentation for this class was generated from the following file:
