IDOMRadialGradientBrush interface. A radial gradient brush defines an ellipse to be filled with the gradient. The ellipse is defined by its center, x radius, and y radius. Independently, a gradient origin is specified for the brush. The gradient origin defines the center of the gradient; a gradient stop with an offset at 0.0 defines the color at the gradient origin. The outer bound of the ellipse defines the end "point" of the gradient; that is, a gradient stop with an offset at 1.0 defines the color at the circumference of the ellipse, and all other gradient stops define their offsets relative to the radial distance between the gradient origin and the circumference. More...

#include <idombrush.h>

Inheritance diagram for IDOMRadialGradientBrush:

[legend]

Classes
class	Data
	Initialization data. More...

Public Member Functions
virtual const FPoint &	getCenter () const =0
	Retrieves the center point of the gradient brush ellipse. More...

virtual void	setCenter (const FPoint &pt)=0
	Sets the center point of the gradient brush ellipse. More...

virtual const FPoint &	getGradientOrigin () const =0
	Retrieves the origin point of the radial gradient, corresponding to the gradient stop with an offset of 0.0. More...

virtual void	setGradientOrigin (const FPoint &pt)=0
	Sets the origin point of the radial gradient, corresponding to the gradient stop with an offset of 0.0. More...

virtual double	getRadiusX () const =0
	Retrieves the x-radius of the gradient brush ellipse. More...

virtual void	setRadiusX (double r)=0
	Sets the x-radius of the gradient brush ellipse. More...

virtual double	getRadiusY () const =0
	Retrieves the y-radius of the gradient brush ellipse. More...

virtual void	setRadiusY (double r)=0
	Sets the y-radius of the gradient brush ellipse. More...

virtual IDOMShadingPatternType3BrushPtr	createShading (IEDLClassFactory *pFactory, const FRect &fillArea, bool useFirstStopColorSpace=false)=0
	Create a Type3 Shading Pattern brush from this radial brush. All alpha information in the gradient stops will be dropped. The resulting brush will be generated to fill the given rectangle. More...

virtual IDOMRadialGradientBrushPtr	getSimplifiedGradient (IEDLClassFactory *pFactory, const FRect &fillArea)=0
	Create a simplified radial gradient brush, where any repeat or reflect pad mode is converted to simple padding by repeating gradient stops as required. The resulting brush will be generated to fill the given rectangle. More...

Public Member Functions inherited from IDOMGradientBrush
virtual eColorInterpolationMode	getColorInterpolationMode () const =0
	Retrieves the color interpolation mode value of the radial gradient brush. More...

virtual void	setColorInterpolationMode (eColorInterpolationMode cim)=0
	Sets the color interpolation mode value of the radial gradient brush. More...

virtual eSpreadMethod	getSpreadMethod () const =0
	Retrieves the spread method value of the RadialGradientBrush element. More...

virtual void	setSpreadMethod (eSpreadMethod sm)=0
	Sets spread method value of the RadialGradientBrush element. More...

virtual void	setGradientStops (const CDOMGradientStopVect &stops)=0
	Set the vector of stops in this gradient. Must not be empty. More...

virtual const CDOMGradientStopVect &	getGradientStops () const =0
	Retrieves the vector of stops in this gradient. An exception will be thrown if the gradient has no stops. More...

virtual void	addGradientStop (const IDOMGradientStopPtr &ptrGradientStop)=0
	Append a gradient stop. More...

virtual void	normalizeStops (IEDLClassFactory *pFactory, const IDOMColorSpacePtr &ptrColorSpace=IDOMColorSpacePtr(), eRenderingIntent intent=eRelativeColorimetric, eBlackPointCompensation bpc=eBPCDefault)=0
	Normalize the gradient stops to a single color space, sort them and ensure there are stops at 0.0 and 1.0. More...

Public Member Functions inherited from IDOMTransformableBrush
virtual const FMatrix &	getRenderTransform () const =0
	Retrieves the render transform matrix. More...

virtual void	setRenderTransform (const FMatrix &matrix)=0
	Sets the render transform matrix. More...

Public Member Functions inherited from IDOMBrush
virtual eBrushType	getBrushType () const =0
	Retrieves the type of the brush. More...

virtual float	getOpacity () const =0
	Retrieves the opacity value of the brush element. More...

virtual void	setOpacity (float opc)=0
	Sets the opacity value of a brush element. More...

virtual IDOMBrushPtr	getAdjustedForUseInTransformedNode (IEDLClassFactory *pFactory, const FMatrix &nodeTransform)
	Get a version of this brush adjusted for use inside a node with the given transform. More...

Public Member Functions inherited from IEDLObject
virtual const CClassID &	getClassID () const =0
	Returns class ID of IEDLObject. More...

virtual bool	init (CClassParams *pData)
	The init() method is called to perform any post-construction initialization of an IEDLObject that has been created by the EDL class factory, before it is actually returned by the factory. More...

virtual bool	clone (IEDLObjectPtr &ptrObject, IEDLClassFactory *pFactory)
	Create a copy of EDLObject. More...

Public Member Functions inherited from IRCObject
virtual void	addRef () const =0
	Increases the reference count of the actual object pointed to. This would take place during an assignment or copying.

virtual bool	decRef () const =0
	Decreases the reference count of the actual object pointed to. When the reference count falls to Zero, it deletes the actual object pointed to. More...

virtual int32	getRefCount () const =0
	Retrieve the current reference count of the actual object pointed to. More...

Static Public Member Functions
static EDL_API IDOMRadialGradientBrushPtr	create (IEDLClassFactory *pFactory, const FPoint &center, const FPoint &gradientOrigin, double radiusX, double radiusY, const CDOMGradientStopVect &stops, float opacity=1.0f, const FMatrix &renderTransform=FMatrix(), eSpreadMethod spreadMethod=eNoSpread, eColorInterpolationMode colorInterpolationMode=eSRgbLinearInterpolation)
	Simplified radial gradient brush creation. Throws an IEDLError on failure. More...

static const CClassID &	classID ()
	Retrieves class id of IDOM. More...

Additional Inherited Members
Public Types inherited from IDOMBrush
enum	eBrushType { eSolidColor , eLinearGradient , eRadialGradient , eImage , eMasked , eVisual , eSoftMask , eTilingPattern , eType1ShadingPattern , eType2ShadingPattern , eType3ShadingPattern , eType4567ShadingPattern , eNull }
	Brush type enumeration. More...

Protected Member Functions inherited from IRCObject
virtual	~IRCObject ()
	Virtual destructor.

Detailed Description

IDOMRadialGradientBrush interface. A radial gradient brush defines an ellipse to be filled with the gradient. The ellipse is defined by its center, x radius, and y radius. Independently, a gradient origin is specified for the brush. The gradient origin defines the center of the gradient; a gradient stop with an offset at 0.0 defines the color at the gradient origin. The outer bound of the ellipse defines the end "point" of the gradient; that is, a gradient stop with an offset at 1.0 defines the color at the circumference of the ellipse, and all other gradient stops define their offsets relative to the radial distance between the gradient origin and the circumference.

Member Function Documentation

◆ classID()

static const CClassID& IDOMRadialGradientBrush::classID ( )

inlinestatic

Retrieves class id of IDOM.

Returns: CClassID Class id of the element

◆ create()

static EDL_API IDOMRadialGradientBrushPtr IDOMRadialGradientBrush::create	(	IEDLClassFactory *	pFactory,
		const FPoint &	center,
		const FPoint &	gradientOrigin,
		double	radiusX,
		double	radiusY,
		const CDOMGradientStopVect &	stops,
		float	opacity = `1.0f`,
		const FMatrix &	renderTransform = `FMatrix()`,
		eSpreadMethod	spreadMethod = `eNoSpread`,
		eColorInterpolationMode	colorInterpolationMode = `eSRgbLinearInterpolation`
	)

static

Simplified radial gradient brush creation. Throws an IEDLError on failure.

Parameters

pFactory	The EDL Class factory to use.
center	The center point of the gradient brush ellipse
gradientOrigin	The origin point of the gradient
radiusX	The x radius of the gradient brush ellipse
radiusY	The y radius of the gradient brush ellipse
stops	The gradient stops
opacity	The alpha to use.
renderTransform	The render transform to use
spreadMethod	The desired spread method
colorInterpolationMode	The desired color interpolation mode

Returns: IDOMRadialGradientBrushPtr The new brush.

◆ createShading()

virtual IDOMShadingPatternType3BrushPtr IDOMRadialGradientBrush::createShading	(	IEDLClassFactory *	pFactory,
		const FRect &	fillArea,
		bool	useFirstStopColorSpace = `false`
	)

pure virtual

Create a Type3 Shading Pattern brush from this radial brush. All alpha information in the gradient stops will be dropped. The resulting brush will be generated to fill the given rectangle.

Parameters

pFactory	The EDL class factory
fillArea	The rectangular area that needs to be filled by the resulting brush.
useFirstStopColorSpace	If true the color space in the first stop will be used for the shading. Otherwise either sRGB or scRGB will be used depending on the interpolation mode.

Returns: IDOMShadingPatternType3BrushPtr The resulting brush.

◆ getCenter()

virtual const FPoint& IDOMRadialGradientBrush::getCenter ( ) const

pure virtual

Retrieves the center point of the gradient brush ellipse.

Returns: FPoint The center point of the gradient brush ellipse.

◆ getGradientOrigin()

virtual const FPoint& IDOMRadialGradientBrush::getGradientOrigin ( ) const

pure virtual

Retrieves the origin point of the radial gradient, corresponding to the gradient stop with an offset of 0.0.

Returns: FPoint The origin point of the radial gradient.

◆ getRadiusX()

virtual double IDOMRadialGradientBrush::getRadiusX ( ) const

pure virtual

Retrieves the x-radius of the gradient brush ellipse.

Returns: double The x-radius of the gradient brush ellipse.

◆ getRadiusY()

virtual double IDOMRadialGradientBrush::getRadiusY ( ) const

pure virtual

Retrieves the y-radius of the gradient brush ellipse.

Returns: double The y-radius of the gradient brush ellipse.

◆ getSimplifiedGradient()

virtual IDOMRadialGradientBrushPtr IDOMRadialGradientBrush::getSimplifiedGradient	(	IEDLClassFactory *	pFactory,
		const FRect &	fillArea
	)

pure virtual

Create a simplified radial gradient brush, where any repeat or reflect pad mode is converted to simple padding by repeating gradient stops as required. The resulting brush will be generated to fill the given rectangle.

Parameters

pFactory	The EDL class factory
fillArea	The rectangular area that needs to be filled by the resulting brush.

Returns: IDOMRadialGradientBrushPtr The simplified brush, or this brush if no action was required. This brush will be cached, so do not edit; make a clone if the returned brush needs to be changed.

◆ setCenter()

virtual void IDOMRadialGradientBrush::setCenter ( const FPoint & pt )

pure virtual

Sets the center point of the gradient brush ellipse.

Parameters

pt	Reference parameter to receive the center point of the gradient brush ellipse.

◆ setGradientOrigin()

virtual void IDOMRadialGradientBrush::setGradientOrigin ( const FPoint & pt )

pure virtual

Sets the origin point of the radial gradient, corresponding to the gradient stop with an offset of 0.0.

Parameters

pt	The origin point of the radial gradient.

◆ setRadiusX()

virtual void IDOMRadialGradientBrush::setRadiusX ( double r )

pure virtual

Sets the x-radius of the gradient brush ellipse.

Parameters

r	The x-radius of the ellipse

◆ setRadiusY()

virtual void IDOMRadialGradientBrush::setRadiusY ( double r )

pure virtual

Sets the y-radius of the gradient brush ellipse.

Parameters

r	The y-radius of the gradient brush ellipse.

The documentation for this class was generated from the following file:

idombrush.h
